OEM Infrared or Radio Frequency Remote Control

The SX-823 is a small form factor OEM remote control enclosure. The SX-823 remote control model has an 18 button rubber keypad and is powered by one CR2025 lithium coin battery.

Simple 3 column by 6 row key matrix allows for many customized key configurations. Custom design options like key colors, case color and backlighting are available.

Custom infrared (IR) and radio frequency (RF) transmission options available. Universal Remote Control (URC) infrared device databases are also available for integration into the remote control design.

SX-832 18 Key Remote Control Front

General Specifications

Max Keys: 18
Dimensions: 3.7 x 1.7 x 0.5 in.
93 x 42 x 12mm
Keypad Type: Silicone Rubber
Feedback LED Available: Yes
Overlay Available: Yes
Back Label Available: Yes
Feedback LED: No
IR Lens: No
Batteries: 2 x AAA

Technical Specifications

Power Consumption: Approx. 50mA at IR transmit
Transmission Distance: 20-30ft (6-9m) Standard
IR Frequency Options: 36KHz-56KHz
RF Frequency Options: 27MHz-2.4GHz
Operating Temperature: +5C to +40C
Storage Temperature: -40C to +70C
Humidity Range: 10% to 90% non-condensing
Compliance: RoHS, REACH

Available Options

Custom Codes:
Button Colors:
Button Printing:
Case Color:
Custom Overlay /
Membrane Keypad:
RF Option:
