SR-52C

OEM Infrared or Radio Frequency Remote Control

Model: SR-52C — 52-Button OEM Remote Control

Key Features:

  • 52-button design with rubber keypad
  • Powered by AAA x 2 batteries
  • Full face overlay allows for unique key configurations to fit specific application design requirements
  • Infrared (IR) and Radio Frequency (RF) transmission options available
  • Compatible with Universal Remote Control (URC) infrared device databases for seamless integration

General Specifications

Max Keys:

52

Dimensions:

8 x 2 x 1in.
200 x 55 x 28mm

Keypad Type:

Rubber Keypad

Feedback LED Available:

Yes

Overlay Available:

Yes

Back Label Available:

Yes

Feedback LED:

Yes

IR Lens:

Yes

Batteries:

2 x AAA

Technical Specifications

Power Consumption:

Approx. 50mA at IR transmit

Transmission Distance:

20-30ft (6-9m) Standard

IR Frequency Options:

36KHz-56KHz

RF Frequency Options:

27MHz-2.4GHz

Operating Temperature:

+5C to +40C

Storage Temperature:

-40C to +70C

Humidity Range:

10% to 90% non-condensing

Compliance:

RoHS, REACH

Available Options

Custom Codes:

Yes

Button Colors:

Yes

Button Printing:

Yes

Case Color:

Yes

Custom Overlay /

Membrane Keypad:

Yes

RF Option:

Yes
