OEM Infrared or Radio Frequency Remote Control

Model: SX-910 — Compact 11-key OEM remote control

Power: Operates on one (1) CR2025 lithium coin-style battery

Key Features:

  • 11-key silicone rubber keypad
  • Domed key matrix beneath rubber keys for enhanced tactile response
  • “Snap feel” dome design provides positive key actuation feedback
  • Compact form factor ideal for handheld or embedded applications

Customization Options:

  • Key and case color variations
  • Optional backlighting
  • Custom infrared (IR) and radio frequency (RF) transmission options

Integration: Compatible with Universal Remote Control (URC) infrared device databases

Availability: Offered in low to medium volumes with infrared (IR) or radio frequency (RF) transmission options

General Specifications

Max Keys:

11

Dimensions:

2.2 x 1.2 x 0.39in.
55 x 30 x 9.8mm

Keypad Type:

Silicone Rubber w/snap

Feedback LED Available:

Yes

Overlay Available:

No

Back Label Available:

Yes

Feedback LED:

Yes

IR Lens:

Yes

Batteries:

1 x CR2025 Lithium Coin


Technical Specifications

Power Consumption:

Approx. 50mA at IR transmit

Transmission Distance:

20-30ft (6-9m) Standard

IR Frequency Options:

36KHz-56KHz

RF Frequency Options:

27MHz-2.4GHz

Operating Temperature:

+5C to +40C

Storage Temperature:

-40C to +70C

Humidity Range:

10% to 90% non-condensing

Compliance:

RoHS, REACH

Available Options

Custom Codes:

Yes

Button Colors:

Yes

Button Printing:

Yes

Case Color:

Yes

Custom Overlay /

Membrane Keypad:

No

RF Option:

Yes
